Heat-Timer Electronic Tempering Valve Package

<< Previous in Electronic Tempering Valves

Price: From $847.46 to $1,822.50

Manufacturer Name: Heat-Timer

Product Options

Size:

Quantity:

DESCRIPTION:

This electronic tempering valve accurately regulates water temperature for a wide variety of applications. The easy-to-read 2-line display and user-friendly adjustment module can be located conveniently up to 500 feet from the valve. This allows outlet water temperature to be monitored at a glance and for the temperature to be adjusted without having to access the valve piping.

The ETV combines a rugged stainless steel valve body, reliable electronic actuator, and a control module with PID-type logic. The control module constantly monitors the outlet temperature of the valve. This current and target temperatures are displayed on a backlit display that can be viewed in virtually any lighting conditions. Based on the adjustable set point, the control employs PID-type logic to adjust the signal sent to the actuator. The actuator mounts directly to the valve body and mixes hot and cold water required to produce the desired outlet temperature.

The PID-type control quickly restores the desired water temperature, even after large changes in load conditions, with a minimum of fluctuation. This makes the ETV ideal for applications with sudden load shifts. The ETV can also accept a switch or time clock signal to incorporate setback. It can even be configured to accept a remote set point signal using its new 4-20mA Set Point input.

FEATURES:
