HT165 Wall-Mounted Condensing Hydronic Boiler

Price: $3,249.00 + Free Shipping!

Manufacturer Name: Laars Heating Systems Company

Manufacturer Part No: HT1.65

Free Shipping

Type:

Quantity:

Specifications:

Features:

Sleek, appliance-grade cabinet that looks great in any location
Up to 96% efficiency, condensing operation
2-year parts warranty, 10-year heat exchanger warranty
Sealed combustion
Direct spark ignition for reliability and smooth starts
Three venting options to meet the needs of almost any installation
Modulating gas valve that varies from 30% to 100% input
Variable speed quiet blower
Boilers are set up for natural gas, no parts necessary for conversion to LP gas
Built in expansion tank that will handle 26.4 gallons of system water
Built in water fill valve
Water flow sensor for hydronic system
Grundfos circulator with air vent and "quick-remove" mounting system
Back-flow preventer
Mounting kit with template and wall bracket for fast and easy installation
Light-weight (100 lbs.) makes handling easy
Stainless steel ASME primary heat exchanger with externally welded manifolds for better flow rates and prevention of leaks
Built-in reverse-pressure by-pass to prevent short cycling
Advanced Siemens control system with temperature control, diagnostics, outdoor reset capability, and easy access for field wiring
Complete piping kit with isolation valves, gas cock, domestic water connection adapters with unions, hydronic connectors with unions
Condensate trap that is easy to inspect & remove from outside the boiler

For more information on this product please view the Sheet(s) below:

Laars LM-5402010 O-Ring Price: $3.18 Baxi Equivalent: 5402010	Laars LM-5402830 NTC Sensor Gasket Price: $3.18 Baxi Equivalent: 5402830 - SOLD INDIVIDUALLY	Laars LM-5409110 Flame Sensing Electrode Gasket Price: $3.18 Baxi Equivalent: 5409110
Laars LM-5401610 Pilot Sight Glass Gasket Price: $3.80 Baxi Equivalent: 5401610	Laars LM-5411420 Fan Gasket Price: $5.10 Baxi Equivalent: 5411420	Laars LM-5410530 Knob Price: $7.88 Baxi Equivalent: 5410530
Laars LM-714010410 Dual Flue Venting Termination Screen Cap Price: $46.08 Baxi Equivalent: 714010410	Laars LM-714059410 1 Meter Polypropelyne Pipe Price: $57.40 Baxi Equivalent: 714059410	Laars LM-714059210 Polypropylene 90 Price: $57.90 Baxi Equivalent: 714059210
Laars LM-714088510 Commercial 1 Meter Coaxial Extension Price: $121.10 Baxi Equivalent: 714088510	Laars LM-714096510 PVC/ABS Adapter Price: $131.78 Baxi Equivalent: 714096510	Laars LM-714088910 Commercial Horizontal Coaxial Termination Price: $176.64 Baxi Equivalent: 714088910
Laars LM-8422840 Ionization Electrode Price: $15.40 Baxi Equivalent: 8422840
