Honeywell RA890F1288 120 VAC Protectorelay
MSRP: $1,312.70
Price: $1,215.12
You Save: $97.58 (7 %)
Please check for availability
Item Number: 7487
Manufacturer Name: Honeywell
Manufacturer Part No: RA890F1288
|
|
Product Manuals and Downloads:
Handbook
Primary control provides solid
state, electronic flame safeguard protection for industrial and
commercial single or dual fuel burners for rectification type flame
detection.
| Features
|
|
• Uses rectification principle of electronic flame detection.
• Replaces RA890E in most applications and mounts on same Q270A1024 Subbase.
• Recycles if flame signal lost while in Run. Failure to establish pilot results in a lockout.
• Safe-start check prevents start-up if flame-simulating failure occurs in flame detector circuit.
• Includes built-in protection against ignition crossover in flame rod systems.
• Includes SPDT alarm contacts.
• Solid state circuitry.
• Mounts and removes easily through use of captive mounting screws.
• Mounting base is made of strong thermoplastic.
|
Product Specifications
|
|
|
| Description
|
Rectification, with alarm contacts
|
|
Application
|
Primary control for rectification application (Flame Rod for example)
|
|
Flame Failure Response Time (sec)
|
3.0 sec
|
|
Safety Switch Timing
|
15 seconds
|
|
Alarm Relay Switching
|
SPDT
|
|
Temperature Range (F)
|
50 Hz models -20 F to +105 F
|
|
Temperature Range (F)
|
60 Hz models -20 F to +115 F
|
|
Temperature Range (C)
|
50 Hz Models -29 C to +41 C
|
|
Temperature Range (C)
|
60 Hz Models -29 C to +46 C
|
|
Dimensions (in.)
|
5 in. high x 5 in. wide x 4 3/4 in. deep (including subbase)
|
|
Dimensions (mm)
|
127 mm high x 127 mm wide x 121 mm deep (including subbase)
|
|
Approvals, Underwriters Laboratories Inc
|
UL Listed: 120V models only; File No. MP268, Guide No. MCCZ
|
|
Approvals, Canadian Standards Association
|
CSA Certified: 120V models only; File No. LR1620
|
|
Approvals, Factory Mutual
|
Approved: Report No. 17678,19417,19784
|
|
|
