009-SF5 Taco Bronze Circulator Less Flanges (Replaces 009-BF5)
MSRP: $608.76
Price: $365.26
You Save: $243.50 (40 %)
Item Number: 9588
Manufacturer Name: Taco
Manufacturer Part No: 009-SF5
|
|
Product Manuals and Downloads:
"00" Series Cartridge Circulator Catalog
009 Circulator Catalog
009 Data Submittal Sheet
"00" Series Replacement Parts List
009 Performance Curve
009-SF5 Taco Bronze Circulator Less Flanges
Model 009 Cartridge Circulator
Performance Data
Flow Range: 0-8 GPM
Head Range: 0-34 Feet
Minimum Fluid Temperature: 40º F (4º C)
Maximum Fluid Temperature: 230º F (110º C)
Maximum Working Pressure: 125 PSI
Connection Sizes: 3/4”, 1”, 1-1/4”, 1-1/2” Flanged
The High Velocity Series Taco 009 Cartridge Circulator is designed for
a wide range of residential and light commercial,
higher-head/lower-flow water circulating applications.
- Available in cast iron or stainless steel construction—stainless steel can be used
in higher-head /lower-flow heat recovery, open-loop solar heating and light commercial/domestic water recirculation systems.
- Unique, “00” family replaceable cartridge contains all of
the moving parts so you can service it easily instead of replacing the
entire unit.
Features
- Standard High Capacity Output
- Compact Design
- Quiet, Efficient Operation
- Unique Replaceable Cartridge Design – Field Serviceable
- Direct Drive-Low Power Consumption
- Self-Lubricating
- No Mechanical Seal
- Unmatched Reliability --Maintenance Free
- Universal Flange-to-Flange Dimensions
- Cast Iron or stainless steel Construction
Typical Applications
- Hydronic Heating
- Radiant In-Floor/Panel Heating
- Closed-Loop Solar Heating Systems
|
