Honeywell RA89A1074 Switching Relay with Internal Transformer, 120V, 1 SPST Line Voltage Relay
MSRP: $106.00
Price: $64.53
You Save: $41.47 (39 %)
Item Number: 3832
Manufacturer Name: Honeywell
Manufacturer Part No: RA89A1074
|
|
Product Manuals and Downloads:
Installation Instructions
Product Data
Provide intermediate switching of a line voltage device from a low voltage controller.
Features
|
|
|
• Integral transformer provides low voltage power for control circuit.
|
Product Specifications
|
|
|
|
Description
|
Switching Relay with internal transformer, for switching one line voltage load.
|
|
Application
|
Provide intermediate switching of a line voltage device form a low voltage controller.
|
|
Coil Ratings Current
|
0.4A
|
|
Coil Ratings Voltage
|
24 Vac
|
|
Temperature Range (F)
|
115 F maximum ambient for 60 Hz. 105 F Max. Ambient for 50 Hz.
|
|
Temperature Range (C)
|
46 C maximum ambient for 60 Hz. 41 C maximum ambient for 50 Hz.
|
|
Dimensions (in.)
|
5 1/4 in. high x 4 1/4 in. wide x 2 5/16 in. deep
|
|
Dimensions (mm)
|
133 mm high x 108 mm wide x 59 mm deep
|
|
Electrical Connections (Control Circuit)
|
2-Wire
|
|
Electrical Ratings
|
Maximum input: 5W
|
|
Electrical Ratings (Maximum Input)
|
5.0 W
|
|
Electrical Ratings (Primary Voltage)
|
120V, 50/60 Hz
|
|
Contacts Electrical Rating Main Contacts 120 Vac
|
10.2A AFL; 61.2A ALR; 10A Resistive
|
|
Contacts Electrical Rating Main Contacts 240 Vac
|
5.1AA ALF; 30.6A ALR; 6.0A Resistive
|
|
Includes
|
Integral transformer, enclosure
|
|
Approvals, Underwriters Laboratories Inc
|
Listed: File No. E4436, Guide No. XAPX
|
|
Approvals, Canadian Standards Association
|
Certified: File No. LR1620
|
|
